Dose-paths in the escalation package

Enumerate every possible dose selection decision for all dose-finding models implemented in the escalation package.

Photo by Jens Lelie on Unsplash

Introduction

Dose-finding clinical trials investigate experimental agents, seeking doses that are tolerable and active. They commonly use some dose-selection model to analyse binary outcomes at increasing doses in cohorts of patients. It is possible to analyse the behaviour of a dose-finding design by exhaustively calculating every possible set of outcomes and invoking the dose selection model on each. We will refer to these hypothetical sequences of doses in response to outcomes as dose-paths.

An example will make this clear. The 3+3 design is widely understood. One of its benefits is its simplicity. Let us investigate the first two cohorts of three patients in the 3+3 variant that permits de-escalation. We calculate dose-paths in escalation using the get_dose_paths function:

library(escalation)
## Loading required package: magrittr
paths <- get_three_plus_three(num_doses = 5, allow_deescalate = TRUE) %>%
  get_dose_paths(cohort_sizes = c(3, 3))

get_dose_paths takes a dose-selection methodology and enumerates every possible path according to the cohort sizes that you specify. The returned paths object contains lot of information but the most pertinent perhaps is the sequence of dose-recommendations in response to hypothetical outcomes:

paths
## Give dose 1:
##   NNN -> 2
##     NNN -> 3
##     NNT -> 2
##     NTT -> 1
##     TTT -> 1
##   NNT -> 1
##     NNN -> 2
##     NNT -> NA
##     NTT -> NA
##     TTT -> NA
##   NTT -> NA
##   TTT -> NA

We see above that the trial starts at dose 1. If three non-toxicities (N) are seen, the algorithm advocates escalation to dose 2. In constrast if two or more toxicities (T) are seen in the first cohort, no dose is selected (the dose is NA) and the trial stops. Subsequent cohorts are represented by greater levels of indentation.

This information is better represented by a graph. If you are using RStudio, the graph will appear in the Viewer pane. (In this vignette, we suppress non-RStudio demonstration of the graphs to avoid problems on CRAN computers.)

graph_paths(paths)

The blue node towards the centre bearing the number 1 represents the start of the trial. The edges of the graph (the lines connecting the nodes) represent the outcomes in cohorts of patients. As before, we see that if three N events are seen, the trial escalates to dose 2. Three patients are assumed to be treated at that dose and from there, further escalation to dose 3 will be advised if no toxicity is seen. In contrast, dose 2 will be retained for a further cohort of three if a single toxicity is seen, and de-escalation to dose 1 will occur if two or more toxicities are seen. This is exactly the behaviour we expect from the 3+3 design.

Dose-paths were introduced in the phase I setting that we consider here by Yap et al. (2017). Their phase I/II analogue was introduced by Brock et al. (2017) for dose-finding trials that consider efficacy and toxicity outcomes.

Other Models

CRM

The above example uses the 3+3 design but other methods are available. In fact, early phase statisticians would much prefer that you use a model-based method (Wheeler et al. 2019). The escalation package is intentionally written so that all dose selectors look the same, regardless the implementation-level details. In computing terminology, dose selectors in escalation support a common interface. This makes it trivial to calculate dose-paths for all dose-selectors - we just use the get_dose_paths function again.

Let us investigate a continual reassessment method (CRM) design now, as described by O’Quigley, Pepe, and Fisher (1990) and implemented by the dfcrm package (Cheung 2013). We must specify a dose-toxicity skeleton, and a target toxicity level:

skeleton <- c(0.05, 0.1, 0.25, 0.4, 0.6)
target <- 0.25

We can then specify a CRM model and calculate dose-paths as before:

paths <- get_dfcrm(skeleton = skeleton, target = target) %>%
  get_dose_paths(cohort_sizes = c(3, 3))

When we graph the paths this time (and adopt a different colour palette for fun):

graph_paths(paths, viridis_palette = 'magma')

we see that the Stop node is absent - all paths recommend a dose, even those seeing substantial toxicity. Stopping behaviours must be specified for the CRM method. Fortunately, escalation makes this simple.

An intuitive method for stopping in the Bayesian setting is to test the posterior distribution for the probability of toxicity. In our example, we will stop if there is at least a 90% probability that the toxicity rate at the lowest dose is 35% or greater:

paths <- get_dfcrm(skeleton = skeleton, target = target) %>%
  stop_when_too_toxic(dose = 1, tox_threshold = 0.35, confidence = 0.9) %>%
  get_dose_paths(cohort_sizes = c(3, 3))

When we visualise the paths from the updated model:

graph_paths(paths, viridis_palette = 'inferno')

we see that some paths once again recommend stopping. The paths that recommend a dose are otherwise unchanged.

BOIN

Another dose-escalation model implemented in escalation is the Bayesian optimal interval (BOIN) method by Liu and Yuan (2015), implemented in the BOIN package (Yuan and Liu 2018).

To spice things up, we will visualise how this model behaves over four cohorts of two patients:

paths <- get_boin(num_doses = 4, target = target) %>%
  get_dose_paths(cohort_sizes = rep(2, 4))
## You have requested 121 model evaluations. Be patient.
graph_paths(paths, RColorBrewer_palette = 'YlOrRd')

The first thing to note about the graph above is that it is much more complex than the previous graphs. The number of nodes in dose-paths increases faster than linearly as more cohorts are considered. Consideration of this must be given when visualising dose-paths.

Secondly, the visual method makes it simple to discern messages about future model behaviour. For instance, we can easily see that dose 4, the darkest red node, is only reached in the first four cohorts if the first cohort sees no toxicity.

In contrast to CRM, BOIN does have a stopping rule for excess toxicity built in. We see that TT in the first cohort is not enough to advocate stopping but that any further toxicity in the second cohort will be sufficient to warrant stopping.

Further options

Non-uniform cohorts

There is no reason that the cohort sizes should be uniform. Specify whatever cohort_sizes you like:

paths <- get_boin(num_doses = 4, target = target) %>%
  get_dose_paths(cohort_sizes = c(3, 1, 2))

graph_paths(paths, RColorBrewer_palette = 'Blues')

You can even evaluate the dose advice after each patient using cohort sizes of 1:

paths <- get_boin(num_doses = 4, target = target) %>%
  get_dose_paths(cohort_sizes = rep(1, 4))

graph_paths(paths, RColorBrewer_palette = 'RdPu')

Partially completed trials

It is possible to calculate dose-paths from trials that are partially completed. For instance, let us continue with our BOIN model and assume that we have seen outcomes 1NNN 2TNT so far in our trial. Thus, we are reasonably sure that dose 1 is safe but wary that dose 2 might be too toxic. However, these beliefs are tempered by the tiny sample size. From this starting point, how might the next two cohorts of three proceed? We just specify the previous outcomes using the previous_outcomes parameter:

paths <- get_boin(num_doses = 4, target = target) %>%
  get_dose_paths(cohort_sizes = rep(3, 2), previous_outcomes = '1NNN 2TNT')

graph_paths(paths, viridis_palette = 'viridis')

Notice how this is different to the advice we get at the start of the trial (i.e. when omitting the previous_outcomes):

paths <- get_boin(num_doses = 4, target = target) %>%
  get_dose_paths(cohort_sizes = rep(3, 2))

graph_paths(paths, viridis_palette = 'viridis')

This is a feature of model-based methods like CRM and BOIN - they use all information at all doses when making dose decisions. They are not memoryless like the 3+3.

Next dose

The dose at which dose-paths commence is inferred from the model. It can be specified manually, however:

paths <- get_three_plus_three(num_doses = 5, allow_deescalate = TRUE) %>%
  get_dose_paths(cohort_sizes = c(3, 3), next_dose = 3)

graph_paths(paths, viridis_palette = 'plasma')

A 3+3 trial with de-escalation enabled will de-escalate through the doses when toxicity is seen, as expected.

Crystallised dose-paths

Calculating dose-paths is useful for visually examining the conditions under which a dose-finding design would escalate or de-escalate or stop. However, that is only part of the story. When we marry dose-paths with assumed true event probabilities, we can calculate exact operating characteristics of a design. We refer to this as crystallising dose paths because the likelihood of each path has been calculated precisely according to an assumed truth.

For instance, we can calculate dose-paths for the first four cohorts of three patients using the CRM with stopping design that we specified previously:

skeleton <- c(0.05, 0.1, 0.25, 0.4, 0.6)
target <- 0.25

paths <- get_dfcrm(skeleton = skeleton, target = target) %>%
  stop_when_too_toxic(dose = 1, tox_threshold = 0.35, confidence = 0.9) %>%
  get_dose_paths(cohort_sizes = rep(3, 4))
## You have requested 341 model evaluations. Be patient.

We can then crystallise the paths using toxicity probabilities that exactly match the beliefs in our skeleton:

true_prob_tox <- skeleton

x <- paths %>% calculate_probabilities(true_prob_tox = true_prob_tox)
x
## Number of nodes: 213
## Number of terminal nodes: 160
##
## Number of doses: 5
##
## True probability of toxicity:
##    1    2    3    4    5
## 0.05 0.10 0.25 0.40 0.60
##
## Probability of recommendation:
##   NoDose        1        2        3        4        5
## 0.000127 0.019866 0.227135 0.451791 0.273014 0.028066
##
## Probability of continuance:
## [1] 1
##
## Probability of administration:
##      1      2      3      4      5
## 0.3172 0.1602 0.1867 0.2734 0.0626
##
## Expected sample size:
## [1] 11.99887
##
## Expected total toxicities:
## [1] 2.705489

We see that in this scenario, the probability of a path stopping and advocating no dose within the first four cohorts is very close to zero. In contrast, when the toxicity probabilities are much greater than anticipated:

true_prob_tox <- c(0.45, 0.6, 0.68, 0.75, 0.81)

x <- paths %>% calculate_probabilities(true_prob_tox = true_prob_tox)
x
## Number of nodes: 213
## Number of terminal nodes: 160
##
## Number of doses: 5
##
## True probability of toxicity:
##    1    2    3    4    5
## 0.45 0.60 0.68 0.75 0.81
##
## Probability of recommendation:
##    NoDose         1         2         3         4         5
## 0.3027462 0.6407708 0.0502073 0.0055527 0.0006931 0.0000299
##
## Probability of continuance:
## [1] 0.697
##
## Probability of administration:
##        1        2        3        4        5
## 0.895800 0.052921 0.008539 0.042028 0.000711
##
## Expected sample size:
## [1] 10.73269
##
## Expected total toxicities:
## [1] 5.102913

the probability of selecting no dose within these first four cohorts is over 30%. The information labelled Probability of continuance: shows the aggregate probability of paths that are continuing to advocate experimentation at doses, i.e. those paths that do not advocate stopping.

We see above that the probability of continuance is 1 minus the probability of selecting no dose. However, this need not necessarily be the case because paths can advocate stopping and recommend a dose. They might do so once it is felt that a suitable dose has been identified. To make this point, let us imagine that we add a rule to our above design that allows stopping once there are 9 patients allocated to the recommended dose. We can think of this as stopping for consensus. Respecifying our model and recalculating dose-paths, we have:

paths <- get_dfcrm(skeleton = skeleton, target = target) %>%
  stop_when_too_toxic(dose = 1, tox_threshold = 0.35, confidence = 0.9) %>%
  stop_when_n_at_dose(dose = 'recommended', n = 9) %>%
  get_dose_paths(cohort_sizes = rep(3, 4))
## You have requested 341 model evaluations. Be patient.
x <- paths %>% calculate_probabilities(true_prob_tox = true_prob_tox)
x
## Number of nodes: 141
## Number of terminal nodes: 106
##
## Number of doses: 5
##
## True probability of toxicity:
##    1    2    3    4    5
## 0.45 0.60 0.68 0.75 0.81
##
## Probability of recommendation:
##    NoDose         1         2         3         4         5
## 0.2103223 0.7393498 0.0440522 0.0055527 0.0006931 0.0000299
##
## Probability of continuance:
## [1] 0.137
##
## Probability of administration:
##        1        2        3        4        5
## 0.895800 0.052921 0.008539 0.042028 0.000711
##
## Expected sample size:
## [1] 9.064864
##
## Expected total toxicities:
## [1] 4.352391

We see that this has reduced our probability of stopping for excess toxicity and inflated our chances of recommending dose 1. Notably, the probability of continuance is now roughly 14%, suggesting that most paths have advocated stopping by now, either for toxicity or concensus.

If we do not like that performance, we can make the consensus stopping rule more demanding by requesting 12 at the recommended dose to advocate stopping:

paths <- get_dfcrm(skeleton = skeleton, target = target) %>%
  stop_when_too_toxic(dose = 1, tox_threshold = 0.35, confidence = 0.9) %>%
  stop_when_n_at_dose(dose = 'recommended', n = 12) %>%
  get_dose_paths(cohort_sizes = rep(3, 4))
## You have requested 341 model evaluations. Be patient.
x <- paths %>% calculate_probabilities(true_prob_tox = true_prob_tox)
x
## Number of nodes: 213
## Number of terminal nodes: 160
##
## Number of doses: 5
##
## True probability of toxicity:
##    1    2    3    4    5
## 0.45 0.60 0.68 0.75 0.81
##
## Probability of recommendation:
##    NoDose         1         2         3         4         5
## 0.3027462 0.6407708 0.0502073 0.0055527 0.0006931 0.0000299
##
## Probability of continuance:
## [1] 0.24
##
## Probability of administration:
##        1        2        3        4        5
## 0.895800 0.052921 0.008539 0.042028 0.000711
##
## Expected sample size:
## [1] 10.73269
##
## Expected total toxicities:
## [1] 5.102913

As usual, deriving an acceptable design is an iterative process. The tools in escalation make it easier to arrive at a design that performs how you want.

Combining dose-paths with true event probabilities allows probabilistic inference on dose-finding designs. This is a novel extension to the use advocated by Yap et al. (2017) and Brock et al. (2017). The use of exact operating characteristics has been implemented for the 3+3 design in the bcrm package (Sweeting and Wheeler 2019). We generalise the method here.

Dose-paths vs simulation

We saw above that probabilistic inference was possible with dose-paths. Researchers have typically used simulation to achieve this task. escalation supports simulation as well through the simulate_trials function. However, this does raise the question, when should you use each method, and what are their relative merits?

The answer to the first question comes down to the expected number of model fits required. Fitting dose-finding models takes computer time. In dose-paths, the model is fit once at each node. We have seen examples above of how the number and size of cohorts affects the number of nodes in dose-paths. In fact, escalation provides a function to calculate the number of nodes.

In a phase 1 dose-finding trial, each patient experiences exactly one of two outcomes: T or N. Let us calculate how many nodes there are in a graph of dose-paths using five cohorts of three patients. We run:

num_dose_path_nodes(num_patient_outcomes = 2, cohort_sizes = rep(3, 5))
## [1]    1    4   16   64  256 1024

The num_patient_outcomes = 2 parameter reflects that patients may experience T or N. The returned vector of integers is the number of nodes at each depth. There is one starting node. That node is connected to four children via outcomes NNN, NNT, NTT, and TTT. The number of nodes at greater depths proceeds multiplicatively thereafter. The total number of nodes is:

num_dose_path_nodes(num_patient_outcomes = 2, cohort_sizes = rep(3, 5)) %>%
  sum
## [1] 1365

Thus it requires exactly 1,365 model fits to calculate the exact operating characteristics in this \(n = 5 \times 3 = 15\) patient scenario. To compare this to simulations, consider that each simulated trial iteration will fit the model up to five times, once at the end of each cohort. The total number of model fits in a simulation study is bounded by this number multiplied by the number of simulated iterations. Generally simulation studies use thousands of replicates, so it is easy to see that exact inference via crystallised dose-paths will be much less computaionally burdensome, and therefore faster here.

In contrast, now consider a trial of eight cohorts of three. The total number of model fits to enumerate the complete graph of dose-paths is

num_dose_path_nodes(num_patient_outcomes = 2, cohort_sizes = rep(3, 8)) %>%
  sum
## [1] 87381

Ten thousand simulated iterations of 8 cohorts each would only require up to 80,000 model fits. Thus, a reasonably accurate simulation study would be expected to be faster here.

However, speed is not the only concern: there is also precision to consider. Simulations have the disadvantage of suffering from Monte Carlo error, that is the uncertainty about the estimated statistics arising from the use of a finite number of simulated iterations. In contrast, exact inference via dose-paths has the great advantage of being exact. That is, there is no uncertainty in the calculated probabilities. (Note: there is still uncertainty about which path will be taken because that is determined by random patient outcomes). Thus, there are scenarios when dose-paths may still be preferable to simulations, even when they are expected to take longer.

It is likely that in practice, simulation is often used when dose-paths would be a better option. If true, that would likely be linked to provision of software that performs the two methods. escalation plugs that gap.

References

Brock, Kristian, Lucinda Billingham, Mhairi Copland, Shamyla Siddique, Mirjana Sirovica, and Christina Yap. 2017. “Implementing the EffTox Dose-Finding Design in the Matchpoint Trial.” BMC Medical Research Methodology 17 (1): 112. https://doi.org/10.1186/s12874-017-0381-x.

Cheung, Ken. 2013. Dfcrm: Dose-Finding by the Continual Reassessment Method. https://CRAN.R-project.org/package=dfcrm.

Liu, Suyu, and Ying Yuan. 2015. “Bayesian Optimal Interval Designs for Phase I Clinical Trials.” Journal of the Royal Statistical Society: Series C (Applied Statistics) 64 (3): 507–23. https://doi.org/10.1111/rssc.12089.

O’Quigley, J, M Pepe, and L Fisher. 1990. “Continual Reassessment Method: A Practical Design for Phase 1 Clinical Trials in Cancer.” Biometrics 46 (1): 33–48. https://doi.org/10.2307/2531628.

Sweeting, Michael, and Graham Wheeler. 2019. Bcrm: Bayesian Continual Reassessment Method for Phase I Dose-Escalation Trials. https://CRAN.R-project.org/package=bcrm.

Wheeler, Graham M., Adrian P. Mander, Alun Bedding, Kristian Brock, Victoria Cornelius, Andrew P. Grieve, Thomas Jaki, et al. 2019. “How to Design a Dose-Finding Study Using the Continual Reassessment Method.” BMC Medical Research Methodology 19 (1). https://doi.org/10.1186/s12874-018-0638-z.

Yap, Christina, Lucinda J. Billingham, Ying Kuen Cheung, Charlie Craddock, and John O’Quigley. 2017. “Dose Transition Pathways: The Missing Link Between Complex Dose-Finding Designs and Simple Decision-Making.” Clinical Cancer Research 23 (24): 7440–7. https://doi.org/10.1158/1078-0432.CCR-17-0582.

Yuan, Ying, and Suyu Liu. 2018. BOIN: Bayesian Optimal Interval (Boin) Design for Single-Agent and Drug- Combination Phase I Clinical Trials. https://CRAN.R-project.org/package=BOIN.

Avatar
Kristian Brock
Statistical Consultant

I am a clinical trial methodology statistician that likes to use Bayesian statistics.
